MAN Marc 4 Steam Turbine 17MW

Backpressure turbine, building year 2007 – MAN type MARC 4 – 17.650 kW.

EXW from our warehouse in Poland.

Technical specifications

Designation Unit Normal Max

Type: MARC 4 – B02

Power kW: 17.650

Rated speed 1/min: 8120

Quick closing speed 1/min: 8650

Main steam pressure bara: 74

Main steam temperature: C 447

Fresh steam quantity t/h: 140

Tap steam pressure 1 bara: 31.8 m

Tap Steam Temp.  C 336

Tap steam pressure 2 bara: 25.2

Tap steam temp.2  C 307

Outlet pressure bara 7,5 abs/6,5 guage

Evaporation temperature: C 182 C

Synchron Generator

Producer: Ellin Motoren

Building Year: 2007

22800 kVA

10500 V +/- 5%

50 HZ

Please contact us for more details.
